User Manual of iVMS-4000(V2.03)
9.1.1 Remote Recording Configuration
9.1.1.1 Encoding Parameters Configuration
Parameters Description
Encoding Parameters Main/Sub stream and Event Parameters
Stream Type Video & Audio or Video stream
Resolution Recording Resolution
Video Quality Highest, higher, high, average, lower, lowest
Bitrate Type Variable & Constant
Max Bitrate Maximum bit rate of the compressed stream
Frame Rate Record frame rate, from 1/16 to full frame
Frame Type BBP,BP & Single P frame
I frame interval The interval between 2 I frames
Video Encode Type User could select different encode type of standard H.264, MPEG4 or HIK.264.
(need special version of IP camera support)
Select 
to enter encoding
parameters configuration interface.
Note: If the device is DS-9000 series,
click “Switch to IP Channel” and select IP
channel to configure the parameters of IP
camera.
65
