User Manual of iVMS-4000(V2.03)
Channel State
30
In preview mode, click the button to
enable the display of the current channel state.
And then the icon will change to , which can
be selected to hide the channel state.
The icons shown on the title bar are
described as below:
No local recording/local recording
Normal signal/signal loss
Normal hardware/abnormal
hardware
Current bitrate level (1~5)
5.4 Two Screen Preview
If the computer has connected two
monitor and opened, there will be
button on the top of it.
Click this button, pop up the pull-down
menu, including ”AUX screen
preview”, ”Electronic map” and ”Remote
VOD”
Click “AUX screen preview”, the second monitor will display the preview window.
The aux screen operation is the same as the main screen, refer to the former chapters.
Note: when the main screen is the 64 divisions, the aux screen can’t be opened. After opened the aux
