User Manual of iVMS-4000(V2.03)
5.6.5 Secondary Output of Hardware Decode
The MD card can output the decoded images twice. Take 4002MD card for example, one 4002MD card can
decode 4 channels CIF images, assume they are channel01, channel02, channel03, and channel04; if one
decoding channel is set as 4 divisions and separately display channel01, channel02, channel03, and channel04,
then the other decoding channel can only support one division and select one decoding channel to output the
image. The descriptions above are defined as secondary output.
Note: The system will clear the
previous configuration information of
the secondary output channel.
Click
in the window division
to display secondary output list.
Enter hardware decode configuration interface, and
tick the channel that set as secondary output and the
channel status will become
37
