Analog Way Eikos - Manual (Page 63)

HOME MENU
[MAIN] [MAIN]
Format : 1920 x 1080 Format : 1920 x 1080
Rate : 50Hz Rate : 50Hz
Lock : internal Lock : internal
MAIN PREVIEW
---------+----------------+-------------
Logo2 | Logo #1 | Logo #8
Logo1 | Logo #1 | Logo #7
Pip2 | SDI 1 | SDI 4
Pip1 | DVI 1 | DVI 2
Live | Input 1 | Input 8
Frame | Frame 1 | Frame 8
MATRIX MODE QUADRAVISION MODE
[OUT 1]
[OUT 2]
Format : 1920 x 1080
Format : 1920 x 1080
Rate : 50Hz
Rate : 50Hz
Lock : internal
Lock : internal
| OUT 1 | OUT 2
---------+--------------+----------
Logo1 | Logo #1 | Logo #8
Live | Input 1 | SDI 4
Frame | Frame 1 | Frame 8
| MAIN | PREVIEW
---------+--------------+----------
Logo1 | Logo #1 | Logo #8
Win.4 | Input 1 | SDI 4
Win.3 | SDI 2 | SDI 4
Win.2 | DVI 1 | DVI 2
Win.1 | Input 1 | Input 8
Frame | Frame 1 | Frame 8
MIXER MODE
