Preview Mode and OSD Settings
The Preview output can display 6 fields on OSD.
To set up your Preview:
Menu → OSD Settings → OSD Fields
Field#1:
Input
Field#2:
Transparency
Field#3:
Border
Field#4:
Opening Effect
Field#5:
Closing Effect
Field#6:
Smooth Move
The OSD fields are not available in Preview Mosaic Mode.
Preview Features
The Preview output can display all adjustments before the Take.
All current layers for the Main are defined by a colorful frame on Preview. They are identified by a letter and
a number with the same color.
Background Frame:
BFx, with x of 1 to 8
Background Live:
Axx, with xx of 1 to 12
PIP#1:
Bxx, with xx of 1 to 12
PIP#2:
Cxx, with xx of 1 to 12
Logo#2:
2Lx, with x of 1 to 8
Logo#1:
1Lx, with x of 1 to 8
Because the number of resources available is limited, the Preview displays only one live or still layer. The
others are only identified by their colorful frame and their number.
Blinking of the Frame of the Preview allows to display the selected layer.
36
Preview Id
The function disables all the display of information in Preview Mode. The colorful frames and numbers with
the same color are disable. To set up your Preview Id:
Menu → Control → Preview Id
