Analog Way Eikos User Manual

Page 37

Output selection settings

To set up the output, go in the Main Output or Preview Output menu and choose first the adapted format/

resolution, and then the appropriate rate for your screens by using the knob button and the Enter button.

Main Output → Output Format → Output rate

Use the native resolution of your screens/projectors in order to obtain the best image quality. In the Preview

Output menu, you can also match the output configuration the Main Output to the Preview Output by check-

ing the case Sync w/Out 1. It allows you to set up your outputs via the output 1 menu.

Preview output → Synch w/Out 1

Some other settings are available too:
-

The Output sync. polarity.

The Gamma: use this feature to set up the output Gamma.

Flicker Filter (Video Out only): apply a flicker filter on your video output.

Analog type: set up the type of synchronisation of your Analog output.

DVI type: set up the type of color space of your Digital output.

HDCP detection: set up to enable/disable the HDCP detection on the output.

Background colour: add a background colour in place of the default black one.

Test pattern: use test pattern on Main or Preview screen to configure your projectors.

*All changes have to be validated by pressing the

ENTER button in order to be saved*

Input Sync. Loss Function

Source output selection

Once your inputs all have been configured, the output settings of the

Eikos must be set according to the

machines plugged on your

Eikos main and preview outputs (video projector, preview monitor...).

* NOTE *: If you want to use HDCP content from your sources, be sure to attach HDCP compliant screens

or projectors. If it’s not the case, the output image could be disabled.

Allows to display a frame or a source in case of sync loss of the selected input. To set up the Sync. Loss

function:

Menu → Control → Sync. Loss → Press Input# or Enabled

The selected input must be activated to be for being visible in case of sync loss.

* NOTE *: The output status can provide you all information about the output in real time. This

feature is particularly needed when HDCP is used with long cable to be sure that the communication

is well handled.

Video Out

The Video Out allows you the same settings as other outputs with some additional specific options:
-

Sharpness:

set up the sharpness on the video out image.

Flicker Filter:

apply a flicker filter on your video output to eliminate flickering.

In Matrix mode, the menu “

Connection Mode” appears. It allows you to choose recording Output

or Output
