16
E8362/3/4B
Test port input
continued
Description Specification Supplemental information
Standard, 014, UNL UNL and 014
Direct receiver access input noise floor 1,2 - Option 080 enabled 4
10 Hz IF bandwidth
10 to 5 MHz < -17 dBm < -17 dBm
5 to 500 MHz < -16 dBm < -16 dBm
500 MHz to GHz < -1 dBm < -1 dBm
to 10 GHz < -11 dBm < -11 dBm
10 to 0 GHz < -1 dBm < -1 dBm
0 to 0 GHz < -1 dBm < -1 dBm Option 016 degrades performance by dB
0 to 50 GHz < -1 dBm < -1 dBm Option 016 degrades performance by dB
1 kHz IF bandwidth
10 to 5 MHz < -107 dBm < -107 dBm
5 to 500 MHz < -106 dBm < -106 dBm
500 MHz to GHz < -11 dBm < -11 dBm
to 10 GHz < -111 dBm < -111 dBm
10 to 0 GHz < -11 dBm < -11 dBm
0 to 0 GHz < -10 dBm < -10 dBm Option 016 degrades performance by dB
0 to 50 GHz < -10 dBm < -10 dBm Option 016 degrades performance by dB
Receiver compression level (measured at test ports)
10 MHz to 0 GHz < 0.1 dB at -5 dBm 5 and < 0.5 dB at +5 dBm
0 to 0 GHz < 0.1 dB at -9.5 dBm 5 and < 0.5 dB at 0 dBm
0 to 0 GHz < 0.1 dB at -1.5 dBm 5 and < 0.5 dB at - dBm
0 to 50 GHz < 0.1 dB at -1.5 dBm 5 and < 0.5 dB at - dBm
System compression level max output power See dynamic
accuracy chart
Third order intercept – Tone spacing from 100 kHz to 5 MHz
Typical:
10 to 150 MHz + dBm
150 to 00 MHz + dBm
00 to 500 MHz +0 dBm
500 MHz to 0 GHz + dBm
0 to 0 GHz +18 dBm
0 to 50 GHz +15 dBm
Third order intercept – Tone spacing from 5 MHz to 20 MHz
Typical:
10 to 500 MHz +0 dBm
500 MHz to 0 GHz +0 dBm
0 to 0 GHz +16 dBm
0 to 50 GHz +15 dBm
Third order intercept – Tone spacing from 20 MHz to 50 MHz
Typical:
10 to 500 MHz +6 dBm
500 MHz to 0 GHz +6 dBm
0 to 0 GHz +0 dBm
0 to 50 GHz +19 dBm
1. Total average (rms) noise power calculated as mean value of a linear magnitude
trace expressed in dBm.
. Typical performance.
. Noise floor may be degraded by 10 dB at particular frequencies (multiples of
5 MHz) due to spurious receiver residuals.
. 0 Hz offset.
5. This compression level comes from the dynamic accuracy curve with -0 dB
reference test port power.
