4.3 Smart Display Modes, continued
4.3.3 Setup Menu, continued
The Setup Menu contains the following items:
Top Line (provides additional information)
• SET UP MENU
•
TO MANUAL SCROLL
• TO COMMS INFO
Second Line (cycles through the following parameters):
See Section 4.6 Smart Display Glossary for descriptions of setup menu parameters.
NOTE:
Default Minimum Maximum
Other Battery Types Other If AlphaCell™ is selected then user
selects between a range of Alpha cells
Float V/C 2.27 V/C 2.10 V/C 2.35 V/C
Accept V/C 2.40 V/C 2.20 V/C 2.45 V/C
Temp Comp 5.0 mV 0.0 mV 5.0 mV
Batt. Capacity* 100 AH 0 1000 AH
Standby Time 0 0 65335
Standby Events 0 0 65335
Total Runtime 0 0 65335
Self Test Off Off Yes
Test Inhibit — 7 Days 7 Days
Test Interval 30 Days 0 Days 360 Days
Test Duration 10 Min 5 Min 180 Min
Test Countdown 0 0 365 Days
Freq. Range 3.0Hz 1.0Hz 6.0Hz
Tap Switch** No No Yes
PIM Option Yes No Yes
Reset Output 1 — No Yes
Reset Output 2 — No Yes
Over Curr1 — 3.0 A 24 A
Over Curr2 — 3.0 A 24 A
Retry Delay 60 Sec 5 Sec 301 Sec
Retry Limit 20 0 40
Over Curr Tol 3000ms 20ms 9000ms
N+1 Valid No No Yes
Set Defaults — No Yes
Language English Spanish/French/Portuguese/German
These items
appear in the setup
menu only
if battery type
Other is selected.
They are preset
(but not displayed)
if AlphaCell™ is
selected.
These items
appear in the setup
menu only
if the optional
PIM is installed.
