Fig. 4-5, Comms Information Display
(Examples are given for values in the display)
4.3 Smart Display Modes, continued
4.3.2 Comms Information Display (with DSM2 or later)
Pressing ENTER while in the Operation Normal screen will open the Comms
Information display (only displayed when paired with suitable communications
module, otherwise display will read “NO DATA”). This mode operates in a similar
fashion as the Operation Normal display. When you first access the information
display, information displays in Auto Scroll mode. Press UP or DOWN to access
information one step at a time. Press ENTER to access the Setup Menu (discussed
in Section 4.3.3, Setup Menu). Press ESCAPE to reactivate Auto Scroll mode. Press
ESCAPE a second time to reactivate Operation Normal mode (up one level).
The Comms Information display contains the following items:
The top line provides additional instructions. Use the arrows to manually scroll.
The second line cycles through the parameters listed above.
COMMS INFO
CM 00:90:EA:00:30:54
CM 192.168.1.151
CM Rx PWR -6.7dBMv
CM Tx PWR 41.0dBMv
DN FREq 369.000Mhz
UP FREq 15.000Mhz
MODEL DSM3x
SW 4.5.9.0_00.77CO-N
BATT A1 = 13.1 A2=14.0
BATT A3 = 13.5 B1 = 13.1
BATT B2 = 14.0 B3 = 13.5
Second line
Top Line
59 017-805-B0-010 Rev. K2
