4.3 Smart Display Modes
4.3.1 Operation Normal
If no alarms are present, the power supply operates in Operation Normal display mode.
In this mode you can view the primary operating parameters of the power supply while
the display auto scrolls through the available menu items at two-second intervals.
In Operation Normal mode the displayed items are all “metered” items and are for
informational purposes only (not programmable) with respect to the operational status of
the power supply.
The Operation Normal menu contains the following items:
Fig. 4-4, Operation Normal Display
(Examples are given for values in the display)
The top line indicates the current screen and provides additional instructions. Use the
arrows to manually scroll.
The second line cycles through the parameters listed above.
*
Only visible in single-step mode
*
*
OPERATION NORMAL
OPER MODE =
LINE
INPUT VOLTAGE
120V
INPUT FREqUENCy
60hz
OUTPUT VOLTAGE
89V
OUTPUT 1 CURRENT
12.2A
OUTPUT 2 CURRENT
12.2A
OUTPUT WATTS
900W
OUTPUT VA
1060
PERCENT LOAD
80%
ChARGER MODE =
FLOAT
BATTERy VOLTS
40.5V
BATTERy TEMP
37C
ChARGER CURRENT
8.2A
12 EVENTS
65 MIN
Second line
Top Line
