4.6.1 Optional Conversion from Single to Dual AC Feed
The AMPS80 HP system is preconfigured from the factory for a single AC feed per phase for inverters and
rectifiers if present. You have the option to convert to dual feed—see (Figure 14 and Figure 15
Figure 14 —
Single AC feed
Figure 15 —
Dual AC Feed
Rectifier
(optional)
Inverters
Make before break
manual bypass
switch (optional)
AMPS80 HP
AC Input
AC Output
Battery
Connection
DC breakers
(optional)
Rectifier
(optional)
Inverters
Make before break
manual bypass
switch (optional)
AMPS80 HP
AC Output
Rectifier AC Input
Battery
Connection
Inverter AC Input
