P Page P-4 PREFACE
LS300 User’s Guide
the alarm horn can be silenced by pressing the Test/Reset push-button on the appropriate channel,
which will silence the alarm horn and can start a new manual Line Leak Test.
The LS300 System Applications – 5 block diagrams
The block diagrams on the next page, Figure P-1, show the 5 different applications possible with this
equipment. Only block diagram #1, Basic Auto-Learn electronic Line Leak Detector (LLD) console,
is covered in this manual, See TS-TPI, TS-1001-, TS-2001, or STP controller User guides for more
information on the other applications. The possible Applications are:
# 1 Basic Auto-Learn electronic Line Leak Detector (LLD) console
# 2 One LS300 Auto-Learn console with TS-TPI plus an INCON ATG (Automatic Tank
Gauge) console for LLD interface
Note: TPC is the designation for a Turbine Pump Controller throughout this
manual
# 3 One LS300 Auto-Learn console with TS-TPI for Turbine Pump Controller (TPC)
interface and an INCON ATG console for LLD and Pump Controller interface
# 4 Two LS300 Auto-Learn consoles for support of up to 8 lines: one console has the
TS-TPI interface circuit board enabling connection to the other LS300 console via a
special RS-232 cable and to the INCON ATG console via RS-485 communication
for LLD interface
# 5 Two LS300 Auto-Learn consoles for line leak detection of up to 8 lines: one console
has the TS-TPI interface circuit board for connection to the other LS300 console via
a special RS-232 cable and connects to the INCON ATG console via RS-485
communication for LLD interface and for Turbine Pump Controller control
TABLE P-1 Console Channel X - Test/Reset PB
See the
Operation
section in this
manual or the
Quick
Reference
Guide
Push
#
Times
Effect
1 Silences Alarm Horn
2 Gross (3 gph / 11 Lph) Line Leak Test
3 Monthly (0.2 gph / 0.8 Lph) Line Leak Test
4 Annual (0.1 gph / 0.4 Lph) Line Leak Test
