Example: Relay Module SCM Setup

Group Name

Parameter Name

Parameter Value

Relay Modules

Module ‘#’

Channels ‘#’

Channel ‘#’

Name Unleaded Solenoid Valve 

Enabled Yes

Type Solenoid

Polarity Normal

Logic OR Logic

Physically Wired As Normally Open

Number of inputs 1

Input ‘#’

Type 4-20mA Input Module

Channel Unleaded SCCM Vacuum Sensor

Channel ‘#’

Name Premium Solenoid Valve 

Enabled Yes

Type Solenoid

Polarity Normal

Logic OR Logic

Physically Wired As Normally Open

Number of inputs 1

Input ‘#’

Type 4-20mA Input Module

Channel Premium SCCM Vacuum Sensor

Channel ‘#’

Name Diesel Solenoid Valve 

Enabled Yes

Type Solenoid

Polarity Normal

Logic OR Logic

Physically Wired As Normally Open

Number of inputs 1

Input ‘#’

Type 4-20mA Input Module

Channel Diesel SCCM Vacuum Sensor
