License Management Setup Dialog Box
The License Management setup dialog box (see figure 52) allows the user to see the installed
license and enter an acquired product license, unlocking the capabilities supported by that
key.
3
1
2
Figure 52. Enter a License Key
1. Obtain the license key from Extron.
2. Click the Install New License button (see a in figure 52 ).
3. Enter the 32 characters of the new license into the license key field ( b ).
4. Click the OK button ( c ).
5. Click the to close the dialog box.
Player Info Setup Dialog Box
The Player Info setup dialog box (see figure 53) allows the user to give the media player a
distinct identity.
Figure 53. Player Info Setup Dialog Box
Enter a name and location in the appropriate fields. Click the to close the dialog box. The
green bar in the field indicates that your selection is being saved.
JMP 9600 Media Player • HTML Operation 50
