Configure serial port Remote 1 as follows:
1. Press the Enter button (see a on figure 26 ). The Com port 1 configuration screen
appears.
2. Rotate the encoder to highlight the value to be set: Mode, Baud Rate, Data Bits, Parity,
or Stop Bits (
b ).
3. Press the Enter button.
4. Rotate the encoder to select the desired setting ( c ). See the note above for available
settings.
5. Press the Enter button ( d ).
NOTE: The values are not changed if you do not press the Enter button.
6. Repeat steps 2 through 5 as necessary to change other configurable parameters.
System Info selection
View a snapshot of the status of the connections and settings of the media player
(see figure 27). Rotate the encoder to scroll to hidden parts of the display.
Figure 27. System Information Screen
JMP 9600 Media Player • Operation 30
