Audio submenu
The Audio submenu (see figure 15) provides controls to set the volume and audio delay
variables for the one or two output groups.
Media player set to 2-channel or
2-channel locked output
Media player set to 1-channel output
Figure 15. Audio Submenu
NOTE: The image shown on the left in figure 15 shows the audio menu when the
media player is set to either 2-channel or 2-channel locked output. The
submenu on the right is 1-channel locked output. Use the
Settings > Video
submenu to select the mode.
Adjust the values as follows:
1. Rotate the encoder knob to highlight the selected variable.
2. Press the Enter button.
3. Rotate the encoder knob to change the selected variable to the desired value.
4. Press the Enter button to enter the variable and “jump” the selection highlight to the
next variable.
JMP 9600 Media Player • Operation 21
