ISS 408 Integrated Seamless Switcher • HTML Operation
57
HTML Operation
This section describes
•
Loading the Startup (Control) Page
•
•
•
•
I/O Configuration Page
The ISS 408 can be controlled and operated through its Ethernet port, connected via a
LAN or WAN, using a Web browser such as the Microsoft
®
Internet Explorer
®.
This chapter
describes the factory-installed HTML pages, which are always available and cannot be
erased or overwritten.
NOTE: If your Ethernet connection to the ISS is unstable, try turning off the proxy server
in your Web browser. In Internet Explorer, click
Tools
>
Internet Options
>
Connections
>
LAN Settings
, uncheck the
Use a proxy server...
box, and
then click
Ok
.
Loading the Startup (Control) Page
Access the switcher using HTML pages as follows:
1.
Start the Web browser program.
2.
Click in the Address field of the browser.
3.
Type the switcher’s IP address in the browser’s Address field.
NOTE: If the value has not been changed, the factory-specified default,
192.168.254.254, is the correct value for this field.
4.
If you want the browser to display a page other than the default page (such as a custom
page that you have created and uploaded), enter a slash (/) and the name of the file to
open.
NOTES:
•
The browser’s Address field should display the address in the following format:
xxx.xxx.xxx.xxx/{optional_file_name.html}
•
The following characters are invalid in file names: {space} ~ @ = ‘ [ ] { } <
> ’ “ ; : | \ and ?.
5.
Press the keyboard
protected.
•
If the switcher is not password protected, proceed to step
7.
•
If the switcher is password protected, the Enter Network Password dialog box
opens (see figure 41 on the next page).
