Command and Response Table for SIS Commands (continued)
ISS 408 Integrated Seamless Switcher • Programming Guide
45
Command Function
SIS Command
(Host to Unit)
Response
(Unit to Host)
Additional description
User presets
NOTE: The
X@
value specified is the output to which the input with the associated user preset is switched.
Save user preset
X@
*
X1(
,
Spr
X@
•
X1(]
Command code is comma. Save the
X@
outputs settings as preset
X1)
.
Recall user preset
X@
*
X1(
.
Rpr
X@
•
X1)]
Command code is period. Recall
preset
X1(
settings for
X@
output.
Freeze
Enable
X@
*1F
X@
Frz1
]
Output a “frozen” video image.
Disable
X@
*0F
X@
Frz0
]
Turn off freeze (output motion video).
View the freeze status
X@
F
X#]
Show the freeze status.
Example:
1F
0
]
Freeze mode is off for the program output.
Test pattern
Select test pattern for an output
X2!
*
X2@
J
Tst
X2!
*
X2@]
Select a test pattern for the
X2!
outputs.
View test pattern
J
X2!
*
X2@]
Show the test pattern.
Example:
J
3*002
]
Crosshatch test pattern was selected for
both outputs.
Set audio gain and attenuation
NOTE: The set gain (G) and set attenuation command (g) are case sensitive. The increment, decrement and view commands are not
case sensitive.
Set gain
X!
*
X2$
G
X!
Aud
X2#]
Set gain for input
X!
to
X2$
dB.
Example:
4*3G
4Aud+•3
]
Set gain for input 4 to 3 dB.
Set attenuation
X!
*
X2%
g
X!
Aud
X2#]
Set attenuation for input
X!
to
X2#
dB.
Increment level
X!
+G
X!
Aud
X2#]
Increase input
X!
audio level by +1 dB.
Decrement level
X!
–G
X!
Aud
X2#]
Decrease input
X!
audio level by –1 dB.
View audio level
X!
g
X2#]
View gain for input
X!
.
Example:
4G
–•3
]
The ISS reports that the input 4 audio
level is at –3 dB of attenuation.
Audio mute
Audio mute on
X@
*1Z
X@
Amt
X#]
Mute the
X@
audio output.
Audio mute off
X@
*0Z
X@
Amt
X#]
Unmute the
X@
audio output.
View audio mute status
X@
Z
X#]
Audio mute is
X#
for
X@
output.
Front panel security lockout (Executive mode)
Disable
0X
Exe0
]
Adjustments and selections can
be made from the front panel.
Enable (lock image adjustments)
1X
Exe1
]
Lock front panel adjustments; adjust
image via RS-232 only.
View the executive mode status
X
X#]
Show executive mode status.
Example:
X
0
]
Executive mode is off.
NOTE:
X!
= Input number
1
through
8
X@
= Output number
1
(program) or
2
(preview)
X#
= Freeze and front panel lock status
0
= off,
1
= on
X1(
= Preset number
01
thru
03
X2)
= RGB delay/dissolve speed
(
00
[RGB] or
01
[dissolve] to
50
)
X2!
= Program/preview output selection
0
= Program Off / Preview Off
2
= Program Off / Preview On
1
= Program On / Preview Off
3
= Program On / Preview On
X2#
= Gain/attenuation
-24dB
to
+
•
9dB
, each step = 1 dB
X2$
= Gain value
Numeric dB value,
0
to
+9
X2%
= Attenuation value
Numeric dB value,
–1
to
–24
