Command and Response Table for SIS Commands (continued)
ISS 408 Integrated Seamless Switcher • Programming Guide
42
Command Function
SIS Command
(Host to Unit)
Response
(Unit to Host)
Additional description
Video mute
Video mute on
X@
*1B
X@
Vmt
X#]
Set the
X@
video output to black.
Video mute off
X@
*0B
X@
Vmt
X#]
Set the
X@
video output to the selected
video input (1 through 8).
View video mute status
X@
B
X#]
Video mute is
X#
for
X@
output.
Input video type
Set video type
X!
*
X%
\
X!
Typ
X%]
Specify input
X!
video type.
Example:
4*3\
4Typ3
]
Specify input 4 type as YUVp.
View video type
X!
\
X%]
Input
X!
video type is
X%
.
Scaler output video type
Set output resolution and rate
X^
*
X&
=
Rte
X^
*
X&]
Command character is “equals”.
Example:
5*4=
Rte05*4
]
Set output to 1024x768 at 85 Hz.
View resolution and rate
=
Rte
X^
*
X&]
Color
NOTES:
•
Color adjustments are available only for interlaced component video (YUVi), S-video, and composite video inputs.
•
The
X@
value specified is the output to which the adjusted input is switched.
Set a specific color value
X@
*
X1)
C
X@
Col
X1)]
Specify the color adjustment.
Increment color value
X@
+C
X@
Col
X1)]
Increase the color setting by one.
Decrement color value
X@
–C
X@
Col
X1)]
Decrease the color setting by one.
View the color value
X@
C
X1)]
Show the color setting.
Tint
NOTES:
•
Tint adjustments are available only for S-video and composite video inputs.
•
The
X@
value specified is the output to which the adjusted input is switched.
Set a specific tint value
X@
*
X1!
T
X@
Tin
X1!]
Specify the tint adjustment.
Increment tint value
X@
+T
X@
Tin
X1!]
Increase the tint setting by one.
Decrement tint value
X@
–T
X@
Tin
X1!]
Decrease the tint setting by one.
View the tint value
X@
T
X1!]
Show the tint setting.
Brightness
NOTE: The
X@
value specified is the output to which the adjusted input is switched.
Set a specific brightness value
X@
*
X1@
Y
X@
Brt
X1@]
Specify the brightness adjustment.
Increment brightness value
X@
+Y
X@
Brt
X1@]
Increase the brightness.
Decrement brightness value
X@
–Y
X@
Brt
X1@]
Decrease the brightness.
View the brightness value
X@
Y
X1@]
Show the brightness setting.
NOTE
:
X@
= Output number
1
(program) or
2
(preview)
X#
= Mute status
0
= off,
1
= on
X%
= Video type
0
= RGB
3
= YUVp
5
= Betacam 60
7
= S-video
1
= RGBcvS
4
= Betacam 50
6
= HDTV
8
= Composite
2
= YUVi
X^
= Switcher resolution
00
= 640x480
05
= 1024x768
10
= 720p
14
= 576p
01
= 800x600
06
= 1280x768
11
= 1080p
15
= 1366x768
02
= 832x624
07
= 1280x1024
12
= 1080i
16
= 1365x768
03
= 848x480
08
= 1360x765
13
= 1400 x 1050
17
= 1280x800
04
= 852x480
09
= 1365x1024
X&
= Video refresh rate
0
= 50 Hz
2
= 60 Hz
4
= 85 Hz
5
= AFL
1
= 56 Hz
3
= 75 Hz
X1)
= Color value
0
thru
127
X1!
= Tint value
0
thru
255
X1@
= Brightness value
0
thru
63
