ISS 408 Integrated Seamless Switcher • Programming Guide 39
Test Pattern
TstX2!*X2@]
A test pattern has been turned on or off from the front panel for one or both outputs. X2! is
the on/off status for either or both outputs and X2@ is the test pattern selected.
Audio Gain and Attenuation
X!AudX2#]
A front panel audio input level adjustment has occurred. X! is input number and X2# is the
audio gain or attenuation level.
Output Video and Audio Mute
X@VmtX#]
A front panel video mute operation has occurred. X@ is the output and X# is the mute status:
0 = off (video not muted), 1 = on (video muted).
X@AmtX#]
A front panel audio mute operation has occurred. X@ is the output and X# is the mute status:
0 = off (audio not muted), 1 = on (audio muted).
Preview Switch Mode
PsmX2^
A front panel audio input level adjustment has occurred. X2^ is the stay or swap status
for preview switch mode. See “ Preview Switch Mode submenu ” on page 23, for a
description of the two switch modes.
PAL Film Mode
X!FlmX#]
The PAL film mode has been selected or deselected from the front panel for the selected
input.
X! is input number and X# is the on/off status for PAL film mode.
Automated Adjustments
Img X#]
The Auto Image feature has been turned on or off from the front panel for all input
selections.
X# is the on/off status.
Aut X#[
The Auto Presets feature has been turned on or off from the front panel for all input
selections.
X# is the on/off status.
Enh X#]
The enhanced mode feature has been turned on or off from the front panel for S-video or
composite video that is tied to both outputs.
X# is the on/off status for the two outputs.
X@ Reconfig ]
The input selected for the X@ output has been adjusted using the Auto Image feature or a
user preset.
