Command and Response Table for SIS Commands (continued)
ISS 408 Integrated Seamless Switcher • Programming Guide 43
Command Function SIS Command
(Host to Unit)
Response
(Unit to Host)
Additional description
Contrast
NOTE: The X@ value specified is the output to which the adjusted input is switched.
Set a specific contrast value X@ * X1@ ^ X@ Con X1@] Specify the contrast adjustment.
Increment contrast value X@ +^ X@ Con X1@] Increase the contrast.
Decrement contrast value X@ –^ X@ Con X1@] Decrease the contrast.
View the contrast value X@ ^ X1@] Show the contrast setting.
Horizontal size
Set a specific horizontal size X@ * X1# : X@ Hsz X1#] Specify the horizontal size.
Increase the horizontal size X@ +: X@ Hsz X1#] Widen the picture.
Decrease the horizontal size X@ –: X@ Hsz X1#] Make the picture narrower.
View the horizontal size X@ : X1#] Show the horizontal size.
Vertical size
Set a specific vertical size X@ * X1# ; X@ Vsz X1#] Specify the vertical size.
Increase the vertical size X@ +; X@ Vsz X1#] Make the picture taller.
Decrease the vertical size X@ –; X@ Vsz X1#] Make the picture shorter.
View the vertical size X@ ; X1#] Show the vertical size.
Horizontal shift
Set a specific horizontal position X@ * X1$ H X@ Hph X1$] Specify the horizontal position.
Increment right X@ +H X@ Hph X1$] Shift the picture right.
Decrement left X@ –H X@ Hph X1$] Shift the picture left.
View the horizontal position X@ H X1$] Show the horizontal position.
Vertical shift
Set a specific vertical position X@ * X1$ / X@ Vph X1$] Specify the vertical position.
Increment up X@ +/ X@ Vph X1$] Shift the picture up.
Increment down X@ – / X@ Vph X1$] Shift the picture down.
View the vertical position X@ / X1$] Show the vertical position.
Top blanking
Set a top blanking value X@ * X1% ( X@ Blt X1%]
Example 1*2( 1Blt2 ] Blank the top two lines of output 1.
Increment top blanking value X@ +( X@ Blt X1%] Increase blanking value 1 line.
Decrement top blanking value X@ –( X@ Blt X1%] Decrease blanking value 1 line.
View the top blanking value X@ ( X@ Blt X1%]
Bottom blanking
Set a bottom blanking value X@ * X1% ) X@ Blb X1%]
Example: 2*5) 2Blb5 ] Blank the bottom five lines of output 2.
Increment bottom blanking value X@ +) X@ Blb X1%] Increase blanking value 1 line.
Decrement bottom blanking value X@ –) X@ Blb X1%] Decrease blanking value 1 line.
View the bottom blanking value X@ ) X@ Blb X1%]
NOTE : X@ = Output number 1 (program) or 2 (preview)
X1@ = Brightness and contrast value 0 thru 63
X1# = Size value range depends on the resolution
X1$ = Centering value range depends on the resolution
X1% = Blanking value 000 thru 200
