ISS 408 Integrated Seamless Switcher • Programming Guide 38
X@VszX1#]
A front panel vertical size adjustment has occurred. X@ is the output number and X1# is the
size variable.
X@HphX1$]
A front panel horizontal centering adjustment has occurred. X@ is the output number and X1$
is the centering variable.
X@VphX1$]
A front panel vertical centering adjustment has occurred. X@ is the output number and X1$ is
the centering variable.
X@BltX1%]
A front panel top line blanking adjustment has occurred. X@ is the output number and X1% is
the blanking variable.
X@BlbX1%]
A front panel bottom line blanking adjustment has occurred. X@ is the output number and X1%
is the blanking variable.
X@PhsX1^]
A front panel pixel phase adjustment has occurred. X@ is the output number and X1^ is the
pixel phase variable.
X@DhzX1&]
A front panel horizontal detail filter adjustment has occurred for the RGB or component
video input tied to output X@ . X1& is the filter variable.
X@DvzX1*]
A front panel vertical detail filter adjustment has occurred for the RGB or component video
input tied to output X@ . X1* is the filter variable.
X@DvzX1*]
A front panel vertical detail filter adjustment has occurred for the S-video or composite
video input tied to output X@ . X1* is the filter variable.
BluX#]
The blue-only mode has been turned on for both outputs or off for both outputs from the
front panel.
X# is the on/off status for the two outputs.
FilX#]
The edge enhancement mode has been turned on for both outputs or off for both outputs
from the front panel.
X# is the on/off status for the two outputs.
RGB Delay and Dissolve Speed
DlyX2)]
A front panel RGB delay adjustment has occurred. RGB delay affects input selections for
the preview output only.
X2) is the delay value, in 0.01 second steps. X2) can be as much as
50 = 5.0 seconds.
DurX2)]
A front panel dissolve speed adjustment has occurred. Dissolve speed affects the duration
of the dissolve function when switching the preview output to the program output.
X2) is the
delay value, in 0.01 second steps. X2) can be as much as 50 = 5.0 seconds.
