4-5 Matrix 12800 Switchers • Programming Guide
PRELIMINAR
Y
Switcher-Initiated Messages
When a local event such as a power-up occurs, the switcher responds by sending a
message to the host. The switcher-initiated messages are listed below (underlined).
] (C) Copyright 2003, Extron Electronics Matrix12800, Vx.xx,date and time ]
The BME initiates the copyright message when it is first powered on or when
connection via Internet protocol (IP) is established. “Vx.xx“ is the firmware version
number. “date and time“ is the date and time of the connection and is only reported
when the connection is made via the Ethernet port.
] Password: ]
The BME initiates the password message immediately after the copyright
message when the controlling system is connected using TCP/IP or Telnet and the
switcher is password protected. This message means that the switcher requires
an administrator or user level password before it performs the commands entered
via this link. The switcher repeats the password message response for every entry
other than a valid password until a valid password is entered.
] Login Administrator ]
— or —
] Login User ]
The BME initiates the login message when a correct administrator or user password
has been entered. If the user and administrator passwords are the same, the
switcher defaults to administrator privileges.
] All Configuration Memory Cleared ]
The BME initiates the memory cleared message when a system reset has occurred.
The BME does not expect a response from the host, but, for example, the host
program might request a new status.
Switcher Error Responses
When the BME receives an SIS command and determines that it is valid, it performs
the command and sends a response to the host device. If the switcher is unable
to perform the command because the command is invalid or contains invalid
parameters, the switcher returns an error response to the host. The error response
codes are:
E01 — Invalid input channel number (too large)
E10 — Invalid command
E11 — Invalid preset number
E12 — Invalid output number (too large)
E13 — Invalid value (out of range)
E14 — Illegal command for this configuration
E17 — Timeout (caused only by direct write of global ties presets)
E20 — Invalid BME number
E21 — Invalid room number
E22 — Busy
E24 — Privilege violation (Ethernet, Extron software only)
E25 — Device not present
