Turbidity and Suspended Solids Transmitter
Immersion Fitting
SuSix
®
sensor
Wall bracket
for extension
SuSix
®
Immersion fitting
order no. 155215
Extension for
universal bracket
Universal
bracket
1000 mm
Insertion Fitting
SuSix
®
sensor
SuSix
®
insertion fitting
order no. 155210
Service
position
Measure
position
Two positions
T
70 mm
126 mm
46 mm
43 mm
187 mm
100 mm
55mm
200 mm
475 mm
380 mm
Ø49 mm
