Xylem SuSix Turbidity and Suspended Solids Transmitter - Manual (Page 55)

55 FW: 841013-005/843003-001
Turbidity and Suspended Solids Transmitter
EN 5.10 SuSix Manual 1406
Set Sensor Name
A unique name and/or number, a function or a location can be assigned
for a sensor (here: "SuSix1"). It is consequently shown on the main display
with up to 4 display lines.
1. Press the up/down keys to highlight the required menu line
(here: Set Sensor Name) and then press OK to select it.
Specify Main Screen
Data Logger
Password
Set Sensor Name
Converter Setup
Display Setup
Back Select OK
Login
Activate/deactivate
Change password
Back Select OK
Set log interval
0010 sec
Back Select >
Data Logger
Set Sensor Name
SuSix1
Back Select >
Set Sensor Name
Select line
Linie 1 - Sensor name
Linie 2 - Meas.
Linie 3 -
Linie 4 -
Linie 5
Back Select OK
Specify Main Screen Converter Setup
Language
Set Clock
Modbus
Factory settings
Display SW version
Back Select OK
Display Setup
Sensor Calibration
Averaging
Units
mA output
Cleaning
Solid curve
High Alarm
Low Alarm
Sensor error
Status
Factory settings
Service Menu
Back Select OK
Select line content
Not in use
Meas.
Homogeneity
Solid curve
Clock
Back Select OK
Password
Type password
0000
Back Select >
Change password
0000
Back Select >
Activate
Deactivate
Back Select OK
Login
Activate/
Deactivate
Change password
SuSix1 [X]
Meas. FTU
Select Setup
Main Menu
Converter Top Display
SuSix1 [X]
Meas. FTU
Select Setup
Converter Top Display
Specify Main Screen
Data Logger
Password
Set Sensor Name
Converter Setup
Display Setup
Back Select OK
Main Menu
SuSix1 [X]
Prim. mg/l
Second 0.1%
Select Setup
1 - Main menus Page1
2. To change the default sensor name (SuSix1), press the left/right keys to
highlight the wanted character.
