About this Manual
This manual is divided into a table of contents, ten chapters, five appendi-
ces, four fold-out pages and one index.
1. Introduction
Contains a presentation of the MJK SuSix
® Turbidity and Suspended
Solids Transmitter, the structure of this manual and the operating prin-
ciples.
2. Safety, Repair and Product Identification
Provide answers to issues regarding safety, mounting, repair,
restrictions and product identification.
3. Sensor Installation
Contains installation guidelines such as correct and wrong positioning
of the sensor in the liquid, min. and max. distances to walls and other
solid faces, and installation in tubes.
4. Sensor Calibration
Turbidity measurements require no calibration, but detailed calibration
procedures and flow charts for suspended solids calibration are avail-
able.
5. Converter
Describes the physical specifications and installation rules for the con-
verter such as power supply, in- and outputs, sensor/converter/
display configurations, etc.
6. System Configuration Examples
Illustrate how SuSix
® Turbidity and Suspended Solids Transmitters can
be interconnected with for example MJK MagFlux ® flow meters in real-
life scenarios.
7. Startup
Describes important checks and basic settings to get started including
the display and keyboard user interface.
8. SuSix ® Menus
Contains a comprehensive description of the SuSix ® menus, options
and utilities.
9. Mechanical Dimensions
Lists the SuSix
® Turbidity and Suspended Solids Transmitter dimen-
sions and specifications.
