Page 66: Turbidity and suspended solids transmitter
66
EN 5.10 SuSix Manual 1406
FW: 841013-005/843003-001
Turbidity and Suspended Solids Transmitter
Sensor error
SuSix
®
has two digital outputs - DO1 with an opto (light triggered) relay
and DO2 with an electro-mechanical relay. They can both be programmed
for a sensor error, whenever the 4 - 20 mA range has been exceeded.
Sensor error
Electro-mechanical relay
Opto relay
Display only
Not in use
Back Select
OK
Electro-mechanical relay
Opto relay
Display only
Delay
00100 ms
Back Select
>
Delay
00100 ms
Back Select
>
Delay
00100 ms
Back Select
>
Relay function
NO
NC
Back Select
Ok
mA indication
High
Low
Off
Back Select
Ok
mA indication
High
Low
Off
Back Select
Ok
mA indication
High
Low
Off
Back Select
Ok
Relay function
NO
NC
Back Select
Ok
Low Alarm
Electro-mechanical relay
Opto relay
Display only
Not in use
Back Select
OK
On at unit
7,42 g/l
Back Select
>
Relay function
NO
NC
Back Select
>
Off at unit
7,42 g/l
Back Select
>
Delay
00100 ms
Back Select
>
Opto relay
Display only
On at unit
7,42 g/l
Back Select
>
Relay function
NO
NC
Back Select
>
Off at unit
7,42 g/l
Back Select
>
Delay
00100 ms
Back Select
>
On at unit
7,42 g/l
Back Select
>
Off at unit
7,42 g/l
Back Select
>
Delay
00100 ms
Back Select
>
Electro-mechanical relay
On at unit
7,42 g/l
Back Select
>
High Alarm
Relay function
NO
NC
Back Select
>
Off at unit
7,42 g/l
Back Select
>
Electro-mechanical relay
Opto relay
Display only
Not in use
Back Select
OK
Delay
00100 ms
Back Select
>
Electro-mechanical relay
Opto relay
Display only
On at unit
7,42 g/l
Back Select
>
Relay function
NO
NC
Back Select
>
Off at unit
7,42 g/l
Back Select
>
Delay
00100 ms
Back Select
>
On at unit
7,42 g/l
Back Select
>
Off at flow
7,42 g/l
Back Select
>
Delay
00100 ms
Back Select
>
