Status
The "Status" option provides an overview of the in- and output status.
Sensor Data
Converter SW. Ver.
Product data
Reset Counter Time
Internal meas. & cal.
Calibrate mA
Test Primary value
Read eventlog
Comunication log
Back On Stock
Back Select Ok
Type password
00000
Back Select >
Pending errors
xxx
xxx
Back Select Ok
Factory settings
Recover factory settings
Cancel
Default
Back Select OK
Status
DO 1 [ x ] Selected function
DO 1 [ \ ] Selected function
DI [ ] Selected function
mA output 10,234 mA
Back Select OK
Pending warnings
xxx
xxx
Back Select Ok
Pending infos
xxx
xxx
Back Select Ok
Pending alarms
xxx
xxx
Back Select Ok
Service Menu
6 - Converter setup 4 Page6
The check boxes can contain four different characters:
X A cross (X) in a check box indicates an active state
/ A blinking forward slant (/) in a check box indicates that the input/
output is in the process of being activated. Eventually it turns into a
steady X.
\ A blinking backward slant (\) in a check box indicates that the
input/output is in the process of being de-activated. Eventually the
check box is cleared
.
An empty check box indicates a de-activated state.
