Floor Level Network (FLN) Set-up
1. Connect FLN to RS-485 connector on drive.
2. Set parameter 8-30, Protocol to FLN.
3. Each drive must have a unique address
assigned in parameter 8-31, Address.
4. Check that the baud rate selected in
parameter 8-32, Baud Rate is correct.
The table below lists the parameters associated
with FLN functions in the drive. Additional setting
are provided to apply customizing of the FLN
communication protocol.
Parameter
Title
Default Setting Desired Setting
8-30
Control Timeout
0
8-04
Control Timeout Function OFF
8-30
Protocol
FC
FLN
8-31
Address
1 through 98
8-32
Baud Rate
9600
4800 or 9600
8-50
Coasting Select
Logic or
8-52
DC Brake Select
Logic or
8-53
Start Select
Logic or
8-54
Reversing Select
Digital Input
8-55
Set-up Select
Logic or
8-56
Preset Reference Select Logic or
FLN Programmable Functions
See the FLN Point Map Table on the following
pages.
