Modbus rtu point map (by function) – Bell & Gossett 176R0649C Technologic 502 Series Pump Controller User Manual
Page 67
67
20-21
03
20210,1 Setpoint #1
0 to Span (in Technologic User Setup Menu)
32
20-22
03
20220,1 Setpoint #2
0 to Span (in Technologic User Setup Menu)
32
20-23
03
20230,1 Setpoint #3
0 to Span (in Technologic User Setup Menu)
32
20-24
03
20240,1 Setpoint #4
0 to Span (in Technologic User Setup Menu)
32
39-03
03
39030
System Operation Mode
0=Manual,1=Auto, 2=Auto Bypass.
8
39-29
03
39290,1 System Flow Rate (GPM)
0 to Span (in Technologic User Setup Menu)
32
16-10
03
16100,1 AFD #1 Power (kW)
0 to Span (in Technologic User Setup Menu)
32
16-15
03
16150,1 Speed %
0 to 100
32
16-13
03
16130
Frequency Output (Hz)
0 to 50/60
16
39-34
03
39340
Lead Pump Number
1 to Pump # (in Technologic User Setup Menu)
16
39-46
03
39460
Active Zone Number
1 to Zone # (in Technologic User Setup Menu)
16
27-03.01
1
03
27030,1 Run Time, Pump #1
0-32767 Hours
32
27-03.02
2
03
27030,1 Run Time, Pump #2
0-32767 Hours
32
27-03.03
3
03
27030,1 Run Time, Pump #3
0-32767 Hours
32
27-03.04
4
03
27030,1 Run Time, Pump #4
0-32767 Hours
32
