Metasys N2 Point Map (continued)
BI
182
Pump #1 Pump Failure
1 = Failure 0 = O.K.
1
BI
183
Pump #2 Pump Failure
1 = Failure 0 = O.K.
1
BI
184
Pump #3 Pump Failure or VFD
1 = Failure 0 = O.K.
1
BI
185
Pump #4 Pump Failure or VFD
1 = Failure 0 = O.K.
1
BI
186
High Suction Alarm
1 = Failure 0 = O.K.
1
BI
147
Low Suction Alarm
1 = Failure 0 = O.K.
1
BI
148
High System Alarm
1 = Failure 0 = O.K.
1
BI
149
Low System Alarm
1 = Failure 0 = O.K.
1
BI
187
NFSD Warning
1 = Warning 0 = O.K.
1
BO
6
System Reset Request
1 = Yes 0 = No
1
BO
5
System Start / Stop
1 = Start 0 = Stop
1
ADF
96
Process Variable #1
0 to Span (in Technologic User Setup Menu)
32
ADF
97
Process Variable #2
0 to Span (in Technologic User Setup Menu)
32
ADF
98
Process Variable #3
0 to Span (in Technologic User Setup Menu)
32
ADF
99
Process Variable #4
0 to Span (in Technologic User Setup Menu)
32
ADF
103
Setpoint #1
0 to Span (in Technologic User Setup Menu)
32
ADF
104
Setpoint #2
0 to Span (in Technologic User Setup Menu)
32
ADF
105
Setpoint #3
0 to Span (in Technologic User Setup Menu)
32
ADF
106
Setpoint #4
0 to Span (in Technologic User Setup Menu)
32
ADF
100
System Flow Rate
0 to Span (in Technologic User Setup Menu)
GPM
32
ADF
7
AFD #1 Power
0 to Span (in Technologic User Setup Menu)
KW
32
ADI
127
System Operation Mode
0=Manual,1=Auto, 2=Auto Bypass.
8
ADF
107
Speed %
0 to 100
%
32
AI
4
Frequency Output
0 to 50/60
Hz
16
ADI
128
Lead Pump Number
1 to Pump # (in Technologic User Setup Menu)
16
ADI
129
Active Zone Number
1 to Zone # (in Technologic User Setup Menu)
16
AI
42
Run Time, Tech500 Unit
0-32767 Hours
32
AI
43
Run Time, Pump #2
0-32767 Hours
32
AI
44
Run Time, Pump #3
0-32767 Hours
32
AI
45
Run Time, Pump #4
0-32767 Hours
32
