Bell & Gossett 176R0649C Technologic 502 Series Pump Controller User Manual
Page 37
37
Quick
Menu
Q1
My Personal Menu
20-21
Sensor Setpoint #1
20-22
Sensor Setpoint #2
20-23
Sensor Setpoint #3
20-24
Sensor Setpoint #4
39-55
Local / Remote
31-00
Bypass Mode (only available with bypass option)
39-46
Active Zone
Q2
Motor Setup
1-21
Motor Power
1-22
Motor Voltage
1-23
Motor Frequency
1-24
Motor Current
1-25
Motor Nominal Speed
4-12
Motor Speed Low Limit
4-14
Motor Speed High Limit
Q3
System Setup
39-06
Last Configuration Setting
20-93
PID Proportional Gain
20-94
PID Integral Time
20-00
Feedback 1 Source
20-03
Feedback 2 Source
20-06
Feedback 3 Source
20-09
Feedback 4 Source
39-26
Flow Measurement Source
6-15
Terminal 53 High Ref./Feedb. Value
6-18
Terminal 53 Reference/Feedback Units
6-25
Terminal 54 High Ref./Feedb. Value
6-28
Terminal 54 Reference/Feedback Units
6-35
Terminal X30/11 High Ref./Feedb. Value
6-38
Terminal X30/11 Reference/Feedback Units
6-45
Terminal X30/12 High Ref./Feedb. Value
6-48
Terminal X30/12 Reference/Feedback Units
3-03
Max Reference Units
39-20
Max Pump Flow (Old Par. 763)
39-31
Pump Alternation Time (Old Par. 770)
39-32
Start Alternation Start Delay Time (NEW)
Table 6-1. Quick Menu Layout
