ASUS AP140R-E1 1U barebone server 5-29
5.5.2 Hardware Monitor
This menu shows the hardware monitoring status. Select an item then
press Enter to display a pop-up menu with the configuration options.
CPU VCORE VOLTAGE 1.45 V
+3.3V VOLTAGE 3.34 V
+12V VOLTAGE 11.91 V
MCH VCORE +1.5V VOLTAGE 1.50 V
DDR +2.5V VOLTAGE 2.57 V
5VCC 4.94 V
5VSB 4.72 V
VBAT VOLTAGE 3.15 V
Voltage Monitor
Item Specific Help
Select Menu
Voltage Monitor
CPU VCORE Voltage, +3.3V Voltage, +12V Voltage, MCH VCORE
+1.5V Voltage, DDR +2.5V Voltage, 5VCC Voltage, +5VSB Voltage,
VBAT Voltage
Auto-detected voltages through the onboard voltage regulators.
Voltage Monitor
M/B Temperature 49 o C/109 o F
CPU Temperature 48 o C/118 o F
Current FAN1 Speed 0 RPM
Current FAN2 Speed 0 RPM
Current FAN3 Speed 0 RPM
Current FAN4 Speed 0 RPM
Current FAN5 Speed 0 RPM
Current FAN6 Speed 0 RPM
Hardware Monitor
Item Specific Help
Press Enter to view.
Select Menu
