ASUS AP140R-E1 1U barebone server 5-19
SuperIO Device
Serial Port 1 [3F8/IRQ4]
Allow you to select the serial port base addresses. Configuration options:
[Disabled] [3F8/IRQ4] [2F8/IRQ3] [3E8/IRQ4] [2E8/IRQ3] [Auto]
Serial Port1 Address [3F8/IRQ4]
SuperIO Device
Item Specific Help
Set Base I/O address
for serial port 1.
Select Menu
SATA Configuration
*** On-Chip Serial ATA Setting ***
On-Chip Serial ATA [Disabled]
SATA Mode IDE
Serial ATA Port0 Mode Primary Master
Serial ATA Port1 Mode Primary Slave
SATA Configuration
Item Specific Help
[Disabled]: Disable
SATA Controller.
[Auto]: Auto-arrange
the BIOS.
[Combined Mode]: PATA
and SATA are combined.
Max. of 2 IDE drives
on each channel.
[Enhanced Mode]:
Enable both SATA and
PATA. Max. of 6 IDE
drives are supported.
[SATA Only]: SATA is
opeating in legacy
mode.
Select Menu
The items SATA Mode, Serial ATA Port0 Mode, and Serial ATA Port1
Mode are configurable only when the On-Chip Serial ATA item is set to
either Combined Mode, Enhanced Mode, or SATA Only.
