2-21 ASUS AP140R-E1 1U barebone server
2.7.5 Optical drive
To uninstall the optical drive:
1. Please use a pin-ejector (paper
clipper may be used) for tray-out..
(or you can open the tray by
pushing the “open botton”)
4. Use a Philips (cross) screwdriver
to remove the two screws that
secure the metal bracket on the
side of the ODD.
5. Remove the bracket to release the
drive.
3. Disconnect the power and signal
cabled connected to the rear of the
ODD.
When changing ODD, the black ODD front plastic housing is already
removed. User can uninstall/install ODD after remove the tray bezel.
2. Then remove the tray bezel
demonstrated in the photo.
