Chapter 2: Hardware setup 2-2
2.1 Chassis cover
Remove the chassis cover to access the internal components or if you
wish to install system devices.
2.1.1 Removing the cover
1. Use a Phillips screwdriver to
remove the screw on each front
end of the top cover.
2. Firmly hold the cover and slide it
toward the rear panel for about
half an inch until it is disengaged
from the chassis.
3. Lift the cover from the chassis.
2. Loosen the two thumbscrews on
the rear panel to release the top
cover from the chassis.
Thumbscrews
1/2 inch
distance
