ASUS AP140R-E1 1U barebone server 5-21
Setting A B C D E F
Auto or Enhanced Mode
Combined Mode x x
Serial ATA Port0 Mode [Primary Master]
Serial ATA Port1 Mode [Primary Slave]
Combined Mode x x
Serial ATA Port0 Mode [Secondary Master]
Serial ATA Port1 Mode [Secondary Slave]
SATA Only x x x x
Parallel and Serial ATA hard disk configurations
On Primary IDE connector
A: Hard disk 1
B: Hard disk 2
On Secondary IDE connector
C: Hard disk 3
D: Hard disk 4
On SATA connectors
E: SATA hard disk 1
F: SATA hard disk 2
Supported
x Disabled
