76
5.3. Serial Modem Card Configuration
Using the extra PC card slot as a modem will allow the user on-line access without tying up a serial
port with an external modem. Most 56Kbps PC serial modem cards are compatible with the PC card
slot. A complete catalog of modem cards supported by the Super Series is listed in Appendix 2. PC
Card Supported By Super Series.
Figure 5-5 PC serial modem card configuration
5.4. ATA/IDE Fixed Disk Card Configuration
The user must configure the total data size required to use the PC ATA/IDE fixed disk card to store the
system and serial port log. The Super Series will automatically locate the total storage size and the
disk space available on the disk.
The user may delete all the files currently on the card by selecting . The user may select
to format the card. The Super Series supports both EXT2 and VFAT file systems for the disk
card.
The user may store or retrieve the Super Series configuration files to/from the disk by
exporting/importing the Super Series configuration.
Figure 5-6 PC ATA/IDE fixed disk card configuration
