Appendix 5. Guide To The Bootloader Menu Program
A 5.1. Overview
The bootloader menu provides a way to recover the Super Series unit using BOOTP/TFTP as a
disaster recovery option and to diagnose the system hardware. If the user presses the key
within 3 seconds after the Super Series unit is powered up, he will enter the bootloader menu program.
From this menu program, the user can set various system parameters, test system hardware and
perform firmware upgrades.
A 5.2. Main Menu
After entering the bootloader menu program, the user will see following main menu page:
Bootloader 1.1.0 (May 23 2003 - 22:48:25)
CPU : XPC855xxZPnnD4 (50 MHz)
DRAM : 64 MB
FLASH : 8 MB
PC CARD : No card
EEPROM : A Type exist
Ethernet : AUTO-NEGOTIATION
Autoboot Start: 0
-----------------------------------------------------------------------------
Welcome to Boot Loader Configuration page
-----------------------------------------------------------------------------
Select menu
1. RTC configuration [ Feb 14 2003 - 11:00:26 ]
2. Hardware test
3. Firmware upgrade [S/W Version : v1.0.0]
4. Exit and boot from flash
5. Exit and reboot
Back, Refresh
----->
Figure A-10 Main Menu Page of Bootloader Menu
A 5.3. RTC Configuration Menu
Using the RTC configuration menu, the user can set the system time of the Super Series.
-----------------------------------------------------------------------------
RTC configuration
-----------------------------------------------------------------------------
Select menu
1. Date(mm/dd/yy) : 02/14/03
2. Time(hh:mm:ss) : 13:27:12
Back, Refresh
