General Information
3
management on more than one port, or disable management on all of the ports,
as desired. These switches limit only IP-based management. Host-to-Remote
management is IP-less and is never blocked from the fiber port. Serial port
management of the unit is available via the console port located at the top of the
module using a Mini-jack adapter.
In addition to defining which ports are used to manage the iMcV-Giga-FiberLinX-
III units, the management DIP switch settings also define what ports the flow of
the Network Provider’s Management Domain traffic can take through the unit.
See Application Examples for information regarding the Management Domain.
DIP Switch 1 = ON for management on the EXT MGMT port.
DIP Switch 2 = ON for management on the DATA port.
DIP Switch 3 = ON for management on the OPTICS or UPLINK port.
SPECIFICATIONS
Environmental Operating temperature range: +32°F to +1°F (0°C to +50°C)
Humidity: 5% to 95%, non-condensing
Altitude: 0 to 10,000 ft.
Storage Temperature:-13°F to +158°F (-25°C to +70°C)
Power Power Consumption (Typical): 731mA @ 5V DC
Standards /
Compliance
 Read/write IEEE 802.1Q VLAN tags
 QoS IEEE 802.1p-based packet prioritization (4 queues [high/low]
with 4 levels of priority)
 IEEE 802.3ab 1000Base-T twisted pair
 IEEE 802.3z 1000Base-X fiber
 IEEE 802.3x Flow Control
 IEEE 802.3i 10Base-T twisted pair
 IEEE 802.3u 100Base-TX twisted pair
 IEEE 802.3u 100Base-FX or SX fiber
Dimensions Single-Slot iMcV-Module
