Appendix D: Unified Management Agent (UMA)
65
APPENDIX D: UNIFIED MANAGEMENT AGENT
(UMA)
UMA operates in conjunction with B&B Electronics devices with on-board
intelligence (e.g., the iMcV-Giga-FiberLinX-III and the iMediaChassis series. For
example, install 20 devices in the chassis at the Central Office (CO), then
connect each to a remote iMcV-Giga-FiberLinX-III unit installed at the customer's
premise (CPL); UMA will then allow users to manage all 40 devices (including the
chassis at the CO) via a single IP address. Users may still assign IP addresses to
each iMcV-Giga-FiberLinX-III and manage them independently when the SNMP
Management Card within the iMediaChassis is omitted.
WITH THE UNIFIED MANAGEMENT AGENT
When an SNMP request for a iMcV-Giga-FiberLinX-III comes in, the SNMP
Management Card in the iMediaChassis passes
the request to the SNMP agent in
the specific module. The SNMP agent in the iMcV-Giga-FiberLinX-III provides the
relevant management information which is then routed via the SNPM
Management Card and supplied to the client GUI (iView
2 ).
WITHOUT THE UNIFIED MANAGEMENT AGENT
When an SNMP request for an iMcV-Giga-FiberLinX-III comes in, the
iMediaChassis cycles through each slot checking for iMcV-Giga-FiberLinX-III
modules. The iMediaChassis sees the first iMcV-Giga-FiberLinX-III modules in
the chassis, and they can be selected, but they cannot be managed; the full
management interface is inaccessible. Management for each iMcV-Giga-
FiberLinX-III requires a separate connection and a separate IP address.
EASY UPGRADES WITH THE UNIFIED MANAGEMENT
AGENT
 Upgrade one or multiple Host (CO) or Remote (CPE) devices with
just a few mouse clicks
 All devices in chassis are fully functional while upgrades are in
process
