Appendix A: iView
2
Management Software
47
The following functions can be performed via iView 2 :
Function Description
Unit
Configuration Display/modify unit information
Port
Configuration
Display/modify port data
Bandwidth Displays settings for Bandwidth configuration
Tables Display statistics tables, including Unit and Port tables,
RMON statistics, MIB-II ifTable and SFP Info.
VLAN Provides configuration for VLAN IDs per port
Advanced Reboot the module; also allows boot trap delay
OAM AH Configure passive and active 802.3ah
OAM CFM Perform 802.1ag for connectivity fault management
Agent Info Displays SNMP agent data
UNIT CONFIGURATION
Select Unit Configuration to display/modify unit information, including IP address
(display only, modification available through iConfig), global flow control,
maximum frame size, and OAMPDU. The Unit Configuration is available within
the Host Config settings and the Remote Config settings.
