Appendix A: iView
2
Management Software
61
The MEP Instance Configuration page offers more details about an individual MEP
as shown below:
OAM CFM: MEP Instance Configuration screen.
From this screen, the user can perform the following functions:
Function Description
Continuity
Check
Enable/disable CCMs and verify the number of CCMs that
have been sent.
Instance
State Details
Verify the current administrative state of the MEP, view the
last defect identified by the MEP, and view the MAC address
of the MEP.
Peer MEPs Create/List/Delete Peer MEPS associated with the MEP
Loopback Activate loopback and see the results of loopback
operations.
Select Data Analysis to perform a channel line rate test, a round trip delay test,
and a return to the main OAM CFM screen by selecting OAM CFM.
