Configuration
33
Both settings must be enabled to enable the port.
Port
Speed
Ctrl
Set the port manually or for Auto Negotiation for the Twisted
Pair ports. By default, the setting is AN. A Force mode can be
selected for both speed and duplex at 10, 100 or 1000Mbps.
Advertise
Ctrl This is the Selective Advertising feature. Selective Advertising,
when used in combination with Auto Negotiation, advertises the
configured speed and duplex mode for the twisted pair ports.
Auto Negotiation must be enabled for Selective Advertising.
Advertise
FlowCtrl This enable/disable feature is the selection for Advertising Flow
Control. Choose this option to change based on the link
partner's capability; by default, it is enabled as Advertise Flow.
Force
FlowCtrl
This is the selection for Force Flow Control; choose this if
enabling Flow Control. You can select Force and select it to
automatically negotiate based on the link partner’s capability.
LFPT
from This is the Link Fault Pass Through (LFPT) diagnostic function. By
default, this is disabled. You can choose any two ports to
configure LFPT in order for the device to report a failure to one
port if a fault occurs on another port.
Unit
FlowCtrl This is the selection for enabling/disabling global flow control.
Once this is set to enabled, you can select the flow control
settings for each port as listed in the above list.
LINK FAULT PASS THROUGH (LFPT)
Link Fault Pass Through (LFPT) is a diagnostic feature that can be enabled or
disabled. When enabled, it allows the end user to visually detect that the Link
and its associated LEDS on the front faceplate of the module are not lit when a
fault occurs. LFPT can be enabled through the SNMP software (iView²) or
serial/Telnet.
The iMcV-Giga-FiberLinX-III has three ports: Data, Optics and EXT management.
LFPT can be enabled between any two ports. For example, if LFPT is configured
as “from” the Optics port “to” the Data port, then when a fault occurs on the
Optics port , both LEDs for those ports will extinguish. The end-user can decide
which port he wants the fault to be reported to, based on which port he wants to
be in control. LFPT allows the fault to be reported down the line through to the
link partner at the end, such as a switch or a router.
