Installation Instructions
5
Switch Function Default
Setting
1 Management on EXT MGMT port ON
2 Management on DATA port OFF
3 Management on OPTICS or UPLINK port OFF
4 Factory use – Do not change ---
5 Factory use – Do not change ---
6 LoSPD SFP
If the model is 1x9, LoSPD is not functional OFF
7 Remote Module OFF
8 Host Module OFF
HOST/REMOTE AND STANDALONE UNITS
The iMcV-Giga-FiberLinX-III can be used as a Host, Remote, or Standalone unit.
Refer to the Application Examples section for examples.
When two iMcV-Giga-FiberLinX-III units are used as a pair, configure one as a
Host unit (DIP Switch 8 = ON) and the other as a Remote unit (DIP Switch 7 =
ON). As a host unit, the iMcV-Giga-FiberLinX-III requests management
information from the attached remote unit. It then displays that information,
along with its own, when queried by SNMP. As a Remote unit, the iMcV-Giga-
FiberLinX-III will respond to requests for management information from an
attached Host unit.
The iMcV-Giga-FiberLinX-III default configuration is as a Standalone unit (DIP
Switches 7 and 8 = OFF).
LOSPD
When LoSPD is set to ON, it will force the SFP mode to run at 100Mbps. If it is
set to OFF, the SFP will run at the highest usable speed determined by the SFP
itself.
MINI-SERIAL PORT
A console port, located on the front faceplate of the module, allows the customer
to use a local RS-232 serial interface for management. A special mini-jack to
DB9-F cable is provided with the product for direct connection to a PC serial port.
