Appendix A: iView
2
Management Software
58
For the first configuration, create an MA after the MD. Select "Configure MA" to
display the OAM CFM Maintenance Association Configuration screen as shown
below:
OAM CFM: Maintenance Association Configuration screen.
NOTE: iView 2 will automatically display this page if there
is no MD yet defined when the user attempts to access
any other menu control.
Select the Domain and Format, and enter the MA name in the Name field. Use
Interval to select the interval for continuity check messaging, and choose
Primary VID, if applicable. To cancel the MA without saving, select Delete. To
store the MA, select Save and the screen is refreshed.
