MAX1385/MAX1386
Dual RF LDMOS Bias Controllers
with I 2 C/SPI Interface
______________________________________________________________________________________ 51
N.C. N.C. CS1+ CS1- CS2- N.C. CS2+ N.C. OPSAFE2 GATE1 GATE2 OPSAFE1
A0/CSB CNVST
SEL
ALARM
SAFE2
N.C.
REFDAC
DXN1
REFADC
DXP1 SAFE1 DGND
PGAOUT2
AV DD
N.C.
AGND
GATEV
DD
GATEGND
AGND
ADCIN2
ADCIN1
DXN2
DXP2
BUSY
N.C.
A1/DOUT
SDA/DIN
SCL
N.C.
A2/N.C.
PGAOUT1
N.C.
N.C.
N.C.
DV DD
MAX1385
MAX1386
AGND
TOP VIEW
*EXPOSED PAD
*EXPOSED PAD INTERNALLY CONNECTED TO AGND
1 2 3 4 5 6 7 8 9 10 11 12
36 35 34 33 32 31 30 29 28 27 26 25
37
38
39
40
41
42
43
44
45
46
47
48
24
23
22
21
20
19
18
17
16
15
14
13
TQFN
+
Pin Configuration Package Information
For the latest package outline information and land patterns, go
to
www.maxim-ic.com/packages .
PACKAGE TYPE PACKAGE CODE DOCUMENT NO.
48 TQFN-EP T4877-6 21-0044
