MAX1385/MAX1386
Dual RF LDMOS Bias Controllers
with I 2 C/SPI Interface
______________________________________________________________________________________ 27
HEX COMMAND
REGISTER DESCRIPTION MNEMONIC
WRITE READ
Analog-to-Digital Conversion ADCCON 62 —
Channel 1 High-Current Threshold IH1 24 A4
Channel 1 High-Temperature Threshold TH1 20 A0
Channel 1 Low-Current Threshold IL1 26 A6
Channel 1 Low-Temperature Threshold TL1 22 A2
Channel 2 High-Current Threshold IH2 2C AC
Channel 2 High-Temperature Threshold TH2 28 A8
Channel 2 Low-Current Threshold IL2 2E AE
Channel 2 Low-Temperature Threshold TL2 2A AA
Coarse DAC1 High Wiper Input HIWIPE1 34 B4
Coarse DAC1 Low Wiper Input LOWIPE1 36 B6
Coarse DAC1 Write-Through High Wiper Input THRUHI1 74 B4
Coarse DAC1 Write-Through Low Wiper Input THRULO1 76 B6
Coarse DAC2 High Wiper Input HIWIPE2 3A BA
Coarse DAC2 Low Wiper Input LOWIPE2 3C BC
Coarse DAC2 Write-Through High Wiper Input THRUHI2 7A BA
Coarse DAC2 Write-Through Low Wiper Input THRULO2 7C BC
Device Configuration DCFIG 30 B0
FIFO Memory FIFO — 80
Fine DAC1 Input Read RDFINE1 — B8
Fine DAC1 Input Register with Autocalibration FINECAL1 38 —
Fine DAC1 Input Without Autocalibration FINE1 50 —
Fine DAC1 Write-Through Input with Autocalibration FINECALTHRU1 78 —
Fine DAC1 Write-Through Input Without Autocalibration FINETHRU1 52 —
Fine DAC2 Input Read RDFINE2 — BE
Fine DAC2 Input Register with Autocalibration FINECAL2 3E —
Fine DAC2 Input Without Autocalibration FINE2 54 —
Fine DAC2 Write-Through Input with Autocalibration FINECALTHRU2 7E —
Fine DAC2 Write-Through Input Without Autocalibration FINETHRU2 56 —
Flag RDFLAG — EA
Hardware Alarm Configuration ALMHCFG 60 E0
PGA Calibration Control PGACAL 4E —
Software Clear SCLR 68 —
Software LDAC LDAC 66 —
Software Shutdown SSHUT 64 —
Software Alarm Configuration ALMSCFG 32 B2
Table 2. Register Listing (See Appendix: Recommended Power-Up Code Sequence section)
