93
A/T8xC5121
4164G–SCR–07/06
Reset Value = XXX0 0000b
Table 67. SCON Register
SCON (S:98h)
Serial Control Registe
7 6 5 4 3 2 1 0
FE/SM0 SM1 SM2 REN TB8 RB8 TI RI
Bit
Number
Bit
Mnemonic Description
7
FE
Framing Error bit
To select this function, set SMOD0 bit in PCON register.
Set by hardware to indicate an invalid stop bit.
Must be cleared by software.
SM0
Serial Port Mode bit 0
To select this function, clear SMOD0 bit in PCON register.
Software writes to bits SM0 and SM1 to select the Serial Port operating mode.
Refer to SM1 bit for the mode selections.
6 SM1
Serial Port Mode bit 1
To select this function, set SMOD0 bit in PCON register.
Software writes to bits SM1 and SM0 to select the Serial Port operating mode.
SM0 SM1 Mode Description Baud Rate
0
0 0 Shift Register F
OSC
/12 or variable if SRC bit in BDRCON is set
0 1 1 8-bit UART Variable
1 0 2 9-bit UART F
OSC
/32 or F
OSC
/64
1 1 3 9-bit UART Variable
5 SM2
Serial Port Mode bit 2
Software writes to bit SM2 to enable and disable the multiprocessor communication and automatic address
recognition features.
This allows the Serial Port to differentiate between data and command frames and to recognize slave and broadcast
addresses.
4 REN
Receiver Enable bit
Clear to disable reception in mode 1, 2 and 3, and to enable transmission in mode 0.
Set to enable reception in all modes.
3 TB8
Transmit bit 8
Modes 0 and 1: Not used.
Modes 2 and 3: Software writes the ninth data bit to be transmitted to TB8.
2 RB8
Receiver bit 8
Mode 0: Not used.
Mode 1 (SM2 cleared): Set or cleared by hardware to reflect the stop bit received.
Modes 2 and 3 (SM2 set): Set or cleared by hardware to reflect the ninth bit received.
1 TI
Transmit Interrupt flag
Set by the transmitter after the last data bit is transmitted.
Must be cleared by software.
0 RI
Receive Interrupt flag
Set by the receiver after the stop bit of a frame has been received.
Must be cleared by software.
