80
A/T8xC5121
4164G–SCR–07/06
Table 57. TH0 Register
TH0 (S:8Ch) - Timer 0 High Byte Register.
Reset Value = 0000 0000b
Table 58. TL0 Register
TL0 (S:8Ah) - Timer 0 Low Byte Register.
Reset Value = 0000 0000b
Table 59. TH1 Register
TH1 (S:8Dh) - Timer 1 High Byte Register.
Reset Value = 0000 0000b
Table 60. TL1 Register
TL1 (S:8Bh) - Timer 1 Low Byte Register.
Reset Value = 0000 0000b
7 6 5 4 3 2 1 0
Bit
Number
Bit
Mnemonic Description
7:0 High Byte of Timer 0
7 6 5 4 3 2 1 0
Bit
Number
Bit
Mnemonic Description
7:0 Low Byte of Timer 0
7 6 5 4 3 2 1 0
Bit
Number
Bit
Mnemonic Description
7:0 High Byte of Timer 1
7 6 5 4 3 2 1 0
Bit
Number
Bit
Mnemonic Description
7:0 Low Byte of Timer 1
